* Tires, rear LT215/85R16E highway, blackwall (Required with (C7A) 10,000 lbs. (4536 kg.) GVWR or (C7N) 12,300 lbs. (5579 kg.) GVWR when ordered on *G33503 models and *G33803 models. Required with (C7N) 12,300 lbs. (5579 kg.) GVWR when ordered on *G33903 models. Not available with (YF2) Ambulance Package, (YF1) RV Package, (B3D) School Bus Package or (ANC) Shuttle Bus Package.)
* Bumper, front painted Black with step-pad (Not available with (ZR7) Appearance Package or (YF1) RV Package.)
* Grille, Black composite with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.)
* Daytime Running Lamps
* Mirrors, outside delete
* Glass, Solar-Ray light-tinted, all windows
* Wipers, front intermittent wet-arm with pulse washers
* License plate kit, front
* Tires, front LT215/85R16E, highway, blackwall (Required with (C7A) 10,000 lbs. (4536 kg.) GVWR or (C7N) 12,300 lbs. (5579 kg.) GVWR when ordered on *G33503 models and *G33803 models. Required with (C7N) 12,300 lbs. (5579 kg.) GVWR when ordered on *G33903 models. Not available with (YF2) Ambulance Package, (YF1) RV Package, (B3D) School Bus Package or (ANC) Shuttle Bus Package.)
* Driver Information Center includes fuel range, average speed, oil life, fuel used, ice warning, engine hours, average fuel economy, tachometer, and maintenance reminders. Compass and outside temperature available if equipped.
* Seats, front bucket with vinyl trim and outboard head restraints (Requires (**W) trim. Not available with SEO (ZP0) delete driver and passenger seats.)
|
|
* Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure
* Warning tones, headlamp on and key-in-ignition
* Theft-deterrent system, vehicle, PASS-Key III
* Heater and defogger with front and side window defoggers
* Defogger, side windows
* Visors, driver and front passenger, padded
* Assist handle, front passenger
* Seating arrangement, driver and front passenger highback bucket, adjustable includes head restraints and vinyl or cloth trim
* Power outlets 2 auxiliary on engine console cover with covers, 12-volt
* Engine, Vortec 6.0L V8 SFI (323 hp [240.8 kW] @ 4600 rpm, 373 lb-ft of torque [503.6 N-m] @ 4400 rpm) (Standard on the *G33903 models. Available on *G33503 or *G33803 model. Includes external oil cooler. Reference the Engine/Axle page for availability.)
* Alternator, 145 amps
|
|
* Frame, ladder-type
* Incomplete vehicle certification
* Suspension, front independent with coil springs and stabilizer bar
* Suspension, rear hypoid drive axle with multi-leaf springs
* Brakes, 4-wheel antilock, 4-wheel disc
* Exhaust, aluminized stainless-steel muffler and tailpipe
* Transmission, 4-speed automatic, heavy-duty electronically controlled with overdrive, tow/haul mode and internal transmission oil cooler (Not available with (LMM) Duramax 6.6L Turbo Diesel V8 engine. Reference the Engine/Axle page for availability.)
* Brake/transmission shift interlock for automatic transmissions
* Battery, 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power
* Audio system, radio provisions only. Includes alarm warning chimes, radio wiring harness, radio antenna and 2 front door speakers (Not available with (UM7) AM/FM stereo or (U1C) AM/FM stereo with CD player or (US8) AM/FM stereo with CD/MP3 player or (US9) AM/FM stereo with MP3 compatible 6-disc in-dash CD changer or (UL5) radio delete or (YF1) RV Package.)
|
|
