* Wheels, 6 - 16" x 6.5" (40.6 cm x 16.5 cm) 8-lug painted steel, heavy duty (Only available with (R05) dual rear wheel configuration)
* Tires, front LT225/75R16E all-season, blackwall (Requires (C7I) 14,200 lbs. (6441 kg) GVWR and (R05) dual rear wheel configuration. Jack and spare tire equipment bracket are not included.)
* Tires, rear LT225/75R16E all-season, blackwall (Requires (C7I) 14,200 lbs. (6441 kg) GVWR and (R05) dual rear wheel configuration. Jack and spare tire equipment bracket are not included.)
* Wheel configuration, rear, dual (Not available with (C4M) 9900 lbs. (4490 kg) GVWR, (JFF) 10,100 lbs. (4581 kg) GVWR or (JL4) StabiliTrak.)
* Bumper, front painted Black with step-pad (Deleted when (ZR7) Chrome Appearance Package is ordered.)
* Grille, Black composite with single rectangular halogen headlamps (Not available with (ZR7) Chrome Appearance Package.)
* Flasher, heavy duty light emitting diode (LED)
* Glass, Solar-Ray light-tinted, all windows
* Mirrors, outside delete (Not available with (5Q7) Upfitter option Blank Sail Panel Delete when ordered with (YF2) Ambulance Package.)
* Wipers, front intermittent wet-arm with pulse washers
* License plate kit, front
* Seating arrangement, driver and front passenger highback bucket includes head restraints and vinyl or cloth trim (Not available with (AJ3) driver-side only frontal air bag.)
* Air conditioning, single-zone manual (Not available with (R6G) air conditioning delete.)
* Seats, front bucket with vinyl trim and head restraints includes inboard armrests (Requires (**W) trim. Not available with SEO (ZP0) delete driver and passenger seats. Includes only driver high-back bucket seat with vinyl trim when ordered with (ZX1) driver-only high-back bucket seating arrangement.)
* Cup holders, 3 on the engine console cover
* Power outlets 2 auxiliary on engine console cover with covers, 12-volt
* Power outlet, 120-volt
* Floor covering, Black rubberized-vinyl front
|
|
* Instrumentation, analog with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure
* Driver Information Center includes fuel range, average speed, oil life, fuel used, ice warning, engine hours, average fuel economy, tachometer and maintenance reminders
* Warning tones, headlamp on and key-in-ignition
* Oil life monitor
* Theft-deterrent system, vehicle, PASS-Key III
* Heater and defogger with front and side window defoggers
* Headliner, cloth, over driver and passenger
* Visors, driver and front passenger, cloth, padded
* Assist handles, driver and right-front passenger
* Lighting, interior with dome light and door handle-activated switches
* Engine, Vortec 6.0L V8 (342 hp [255.0 kW] @ 5400 rpm, 373 lb-ft of torque [503.6 N-m] @ 4400 rpm) (Includes external oil cooler. Reference the Engine/Axle page for availability.)
* Transmission, 6-speed automatic, heavy-duty electronically controlled with overdrive and tow/haul mode and internal transmission oil cooler (Reference the Engine/Axle page for availability.)
* Rear Axle, 4.10 Ratio (Included with (L96) Vortec 6.0L V8 and (C7I) 14,200 lbs. (6441 kg) GVWR.)
* Body, standard
* GVWR 14,200 lbs. (6441 kg)
* Tow/haul mode selector, instrument panel-mounted
* Transmission oil cooler, external
* Rear wheel drive
|
|
* Battery, 600 cold-cranking amps maintenance-free with rundown protection and retained accessory power
* Alternator, 150 amps
* Frame, ladder-type
* Incomplete vehicle certification
* Suspension, front independent with coil springs and stabilizer bar
* Suspension, rear hypoid drive axle with multi-leaf springs
* Steering, power
* Brakes, 4-wheel antilock, 4-wheel disc
* Fuel tank capacity, mid-frame and approximately 33 gallons (124.9L)
* Exhaust, aluminized stainless-steel muffler and tailpipe
* Daytime Running Lamps
* Brake/transmission shift interlock for automatic transmissions
* Air bags, frontal, driver and right-front passenger (Included with (ZX2) driver and front passenger high-back bucket seats. Not available with (ZX1) driver only high-back bucket seat. Always use safety belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
* Air bag deactivation switch, frontal, passenger-side (Always use safety belts and the correct child restraints. NOTE: Passenger seat is removed when ordered. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
* Audio system, AM/FM stereo with MP3 player seek-and-scan, digital clock, TheftLock, random select, auxiliary jack and 2 front door speakers (Not available with (YF1) RV Package.)
|
|
